AC-105 Residential Wheelchair Lift

The residential wheelchair lift AC-105 model offers travelling in straight stairways. The Atlas stair lift platform has a smooth ride, it will provide you greater accessibility of your home. The inclined platform lift esthetic and ergonomic design is ideal for all types of residential housing.

Device Category

  • Residential wheelchair lift, indoor use
  • Inclined, open shaft
  • Inclined Platform Lift is for one person in a wheelchair
  • Floor dimensions : 760mm x 1120mm (30 in x 44 in)
  • Other dimensions that meet the B613-00 standard are available on special request
  • 90 degree entry/exit possible

Technical Specifications

  • Maximum capacity : one person in a wheelchair
  • Maximum load : 227 kg (500 lbs)
  • Drive type : Steel cable on winding drum
  • Motor : DC, 24 volts
  • Nominal speed : 0.08 m/s (16 fpm)
  • Brakes : parachute type
  • Floor and side protector arms can be manually retracted as standard feature. A motorized retraction system is available as an option
  • CSA Certification LR45147
  • Controller and panel : industrial grade components from Télémecanique
  • Ramp is varnished natural wood, color matched to existing staircase
  • Anti-skid floor surface
  • Quick installation
